ESDALC6V1C2 Datasheet - STMicroelectronics

Description
The ESDALC6V1C2 is a monolithic array designed to protect up to 4 lines againast ESD transients. The device is ideal for applications where both reduced line capacitance and board space saving are required.

FEATUREs
■ 4 unidirectional TRANSIL functions.
■ Breakdown voltage VBR = 6.1 V min.
    – Low diode capacitance (12 pF @ 0 V)
    – Low leakage current (< 500 nA @ 3 V)
    – very small PCB area (1.33 mm2)
■ Coated lead free package

Benefits
■ High ESD protection level
■ High integration
■ Suitable for high density boards

APPLICATIONs
Where transient overvoltage protection in ESD sensitive equipment is required, such as:
■ Computers
■ Printers
■ Communication systems and cellular phones
■ Video equipment
This device is particularly adapted to the protection of symmetrical signals
