DMF-50834NFJ-SEB Datasheet - Optrex Corporation

General Specifications
   Operating Temp. : min. -10˚C ~ max. 60˚C (Without Backlight)
   Storage Temp. : min. –20˚C ~ max. 70˚C
   Dot Pixels : 119 (W) x 73 (H) dots
   Dot Size : 0.33 (W) x 0.33 (H) mm
   Dot Pitch : 0.36 (W) x 0.36 (H) mm
   Viewing Area : 46.8 (W) x 30.2 (H) mm
   Outline Dimensions : 58.8* (W) x 39.6** (H) x 13.5 max. (D) mm
                                      * Without CFL Cable
                                      ** Without Flat Cable
   Weight : 17g max.
   LCD Type : NTD-15958
                      ( F-STN / Black & White - mode / Transflective )
   Viewing Angle : 6:00
   Data Transfer : 8-bit parallel data transfer
   Backlight : Electro Luminescence (EL) / Blue-green
   Appendix : Component Parts List
   Drawings : Dimensional Outline UE-39683
                     Circuit Diagram UE-36981E
