AM29SL400C Datasheet - Advanced Micro Devices

General Description
   The Am29SL400 is an 4Mbit, 1.8 V volt-only Flash memory organized as 524,288 bytes or 262,144 words. The device is offered in 48-pin TSOP and 48-ball FBGA packages. The word-wide data (x16) appears on DQ15–DQ0; the byte-wide (x8) data appears on DQ7–DQ0. This device is designed to be programmed and erased in-system with a single 1.8 volt VCC supply. No VPP is required for write or erase operations. The device can also be programmed in standard EPROM programmers.

Distinctive Characteristics
◾ Single power supply operation
   — 1.65 to 2.2 V for read, program, and erase operations
   — Ideal for battery-powered applications
◾ Manufactured on 0.32 µm process technology
◾ High performance
   — Access times as fast as 100 ns
◾ Ultra low power consumption (typical values at 5 MHz)
   — 1 µA Automatic Sleep Mode current
   — 1 µA standby mode current
   — 5 mA read current
   — 20 mA program/erase current
◾ Flexible sector architecture
   — One 16 Kbyte, two 8 Kbyte, one 32 Kbyte, and
      seven 64 Kbyte sectors (byte mode)
   — One 8 Kword, two 4 Kword, one 16 Kword, and
      seven 32 Kword sectors (word mode)
   — Supports full chip erase
   — Sector Protection features:
      A hardware method of locking a sector to
      prevent any program or erase operations
      within that sector
      Sectors can be locked in-system or via
      programming equipment
      Temporary Sector Unprotect feature allows code
      changes in previously locked sectors
◾ Unlock Bypass Program Command
   — Reduces overall programming time when
      issuing multiple program command sequences
◾ Top or bottom boot block configurations available
◾ Embedded Algorithms
   — Embedded Erase algorithm automatically
      preprograms and erases the entire chip or any
      combination of designated sectors
   — Embedded Program algorithm automatically
      writes and verifies data at specified addresses
◾ Minimum 1,000,000 erase cycle guarantee per sector
◾ 20-year data retention at 125°C
◾ Package option
   — 48-ball FBGA
   — 48-pin TSOP
