ACM2004E SERIES LCD MODULE

MECHANICAL SPECS
1. Overall Module Size
    182.0mm(W) x 90.0mm(H) x max 13.0mm(D) for LED backlight version
    182.0mm(W) x 90.0mm(H) x max 9.50mm(D) for reflective version
2. Dot Size 1.10mm(W) x 1.50mm(H)
3. Dot Pitch 1.20mm(W) x 1.60mm(H)
4. Duty 1/16
5. Controller IC ST7066
6. LC Fluid TN, STN
7. Polarizer Reflective, Transflective, Transmissive
8. Viewing Angle Bottom, Top
9. Backlight Side LED
10. Temperature Range Standard(0”C ~ 50”C), Wide(-20”C ~ 70”C)
