C8051F362-GM

Mixed Signal ISP Flash MCU Family

Silicon Laboratories

C8051F360/1/2/3/4/5/6/7/8/9

3. Global Electrical Characteristics

Table 3.1. Global Electrical Characteristics

–40 to +85 °C, 25 MHz system clock unless otherwise specified.

Parameter

Conditions

Min Typ Max Units

Digital Supply Voltage

SYSCLK = 0 to 50 MHz

SYSCLK > 50 MHz

2.7 3.0 3.6

V

3.0 3.3 3.6

Digital Supply RAM Data

Retention Voltage

— 1.5 —

V

SYSCLK (System Clock)1,2 C8051F360/1/2/3/4/5

C8051F366/7/8/9

0 — 100 MHz

0 — 50 MHz

Specified Operating

Temperature Range

–40 — +85 °C

Digital Supply Current—CPU Active (Normal Mode, fetching instructions from Flash)

IDD2

VDD = 3.6 V, F = 100 MHz

— 68 75 mA

VDD = 3.6 V, F = 25 MHz

— 21 25 mA

VDD = 3.0 V, F = 100 MHz

— 54 60 mA

VDD = 3.0 V, F = 25 MHz

— 16 18 mA

VDD = 3.0 V, F = 1 MHz

— 0.48 — mA

VDD = 3.0 V, F = 80 kHz

— 36 —

µA

IDD Supply Sensitivity3

F = 25 MHz

F = 1 MHz

— 56 — %/V

— 57 — %/V

IDD Frequency Sensitivity3,4 VDD = 3.0 V, F <= 20 MHz, T = 25 °C

VDD = 3.0 V, F > 20 MHz, T = 25 °C

— 0.45 — mA/MHz

— 0.38 — mA/MHz

VDD = 3.6 V, F <= 20 MHz, T = 25 °C

— 0.61 — mA/MHz

VDD = 3.6 V, F > 20 MHz, T = 25 °C

— 0.51 — mA/MHz

Rev. 1.0

33
