Low voltage 16-bit constant current LED sink driver with output error detection and auto power-saving for automotive applications

STMicroelectronics

STAP16DPPS05

Typical characteristics

Figure 15. Power dissipation vs. package temperature

Note:

The exposed pad should be soldered to the PCB to obtain the thermal benefits.

Figure 16. Turn-ON output current

characteristics(1)

Figure 17. Turn-OFF output current

characteristics(2)

$0Y

AM13667v1

1. The reference level for the TON characteristics is 50% of OE/DM2 signal and 90% of output current

2. The reference level for the TOFF characteristics is 50% of OE/DM2 signal and 10% of output current

Electrical conditions:

– VDD = 3.3 V, Vin = VDD, Vled = 3.0 V, RL = 60 Ω, CL = 10 pF.

– Ch1 (yellow) = OE/DM2, Ch2 (blue) = SDI, Ch3 (purple) = VOUT, Ch4 (green) =

OUT.

DocID024306 Rev 6

19/33
