STPS2H100AF Datasheet PDF : 12 Pages
| |||
STPS2H100
Ref.
A1
A2
b
c
E
E1
D
L
Package information
Figure 20. SMA footprint (dimensions in mm)
1.4
2.63
1.4
1.64
5.43
Figure 21. SMB dimension definitions
E1
D
E
A1
C
A2
L
b
Table 6. SMB dimension values
Dimensions
Millimeters
Min.
Max.
Min.
1.90
2.45
0.075
0.05
0.20
0.002
1.95
2.20
0.077
0.15
0.40
0.006
5.10
5.60
0.201
4.05
4.60
0.159
3.30
3.95
0.130
0.75
1.50
0.030
Inches
Max.
0.096
0.008
0.087
0.016
0.220
0.181
0.156
0.059
DocID6115 Rev 8
7/12
12
