M45PE40-VMN6TP

4 Mbit, low voltage, Page-Erasable Serial Flash memory with byte-alterability and a 50 MHz SPI bus interface

Numonyx -> Micron

Part numbering

12 Part numbering

M45PE40

Table 19. Ordering information scheme

Example:

M45PE40 –

V MP 6 T G

Device type

M45PE = Page-Erasable Serial Flash memory

Device function

40 = 4 Mbit (512 Kb × 8)

Operating voltage

V = VCC = 2.7 V to 3.6 V

Package

MW = SO8W (208 mils width)

MN = SO8N (150 mils width)(1)

MP = VFQFPN8 6 × 5 mm (MLP8)

Device grade

6 = Industrial temperature range, –40 to 85 °C.

Device tested with standard test flow

Option

blank = Standard Packing

T = Tape and Reel Packing

Plating technology

P or G = ECOPACK® (RoHS compliant)

1. Package available only in T9HX technology.

For a list of available options (speed, package, etc.), for further information on any aspect of

this device, or when ordering parts operating at 50 MHz (0.11 µm technology, process digit

“4”), please contact your nearest Numonyx Sales Office.

The category of second Level Interconnect is marked on the package and on the inner box

label, in compliance with JEDEC Standard JESD97. The maximum ratings related to

soldering conditions are also marked on the inner box label.

44/46
