CS5351
(Rev.:2002)

108 dB, 192 kHz, Multi-Bit Audio A/D Converter

Cirrus Logic

6 PACKAGE DIMENSIONS

24L SOIC (300 MIL BODY) PACKAGE DRAWING

CS5351

EH

1

b

c

D

SEATING

PLANE

e

A

A1

∝

L

INCHES

MILLIMETERS

DIM

MIN

MAX

MIN

MAX

A

0.093

0.104

2.35

2.65

A1

0.004

0.012

0.10

0.30

B

0.013

0.020

0.33

0.51

C

0.009

0.013

0.23

0.32

D

0.598

0.614

15.20

15.60

E

0.291

0.299

7.40

7.60

e

0.040

0.060

1.02

1.52

H

0.394

0.419

10.00

10.65

L

0.016

0.050

0.40

1.27

∝

0°

8°

0°

8°

22

DS565PP2
